Core I5 or I7 ,6 or above desktop CPU, Kingston 120G SSD Drive, 4G MEMORY

Can choose to match 9.1/10.0/10.1/11.0/11.1 multi-version system, supporting customization

12 physical 5-pin opto-isolated DMX output, up to 6,144 channels

Supports 64 lines , can be extended to up to 64 DMX outputs with AT series , 32,768 channels

3 metal shaft optical attribute encoders (for adjusting attribute)

4 metal shaft optical attribute encoders with press function (for adjusting playback)

A 15.6-inch capacitive touch screen with window control and editing functions

A 7-inch auxiliary capacitive touch screen can display any content with toggle display function

6 LCD screens, real-time display program storage, running state

40 precise playback faders corresponding to the screen

20 programmable macro function buttons

40 independent flash buttons configured by the user

5 Ethercon network connection, and network switch, can stably transmit signals over 100 meters

2 SC fiber ports and a network switch can stabilize the output signal over 3000 meters

Built-in UPS system, protect the system from unexpected power-off for one hour

Supports 3.5mm and 6.5mm audio output

3 USB ports, 1 at the front and 2 at the back

Support external touch screen

Support MIDI time code, SMPTE time code, built-in music time code, Trigger trigger, built-in time code and other trigger ways, fast realization of sound and light synchronization

Ergonomic trim and handles,convenient and easy-to-use key layout

Support ios and Android remote control （Router connection is required)
