● Equipped with I3 CPU 60G solid state drive, 4G running memory
●Quart machine installation 9.1/10.0/10.1-11.0 four versions of the arbitrary switching operating system
● Ultra-compact shape is only 42.5cm wide
● 3 metal precision photoelectric encoders
● 10 groups of assignable playback faders
(Connected to the Titan Mobile Wing Titan Mobile Wing can be expanded to add 20 sets of playback faders)
● 20 custom function buttons (video work window “Workspaces” / macro “Macros” / execute “playback”)
(Connected to the Titan Mobile Wing Titan mobile wing expandable to add 30 custom function buttons)
● 2048 channels 4 independent DMX512 outputs, plus an Ethernet extender to increase output channels to 8192
(Extensible to 32768 output channels via Titan Net Processor)
● Built-in UPS can run for 1 hour in case of power failure
● Equipped with 14.1” precision touch screen
● The system supports dual display
● Panel mounted super high speed USB 3.0 interface, Gigabit network port
● MIDI input control lighting effects and trigger time code automatic replay performance program
● Compatible with smart mobile phones Android and Apple system remote control operations
● Support multi-band sound trigger (sound-to-light)
● Uniform button layout with other Titan series consoles
● 1000 virtual trigger playback buttons
● Provide multi-language operation interface
● Leading Titan operating system
● Strong field running sequence control
● Built-in lighting simulator and light library writing software
● Multiple working windows provide easy operation and configuration of fixture data
● Performance files are common to all Titan system consoles
● With video media material thumbnail preview and operating system
● Unique “Quicketch” hand-drawn tool for quickly creating custom graphic annotations
● Network tracking backup, multi-user system
● Light matrix pixel image programming function
● Configurable group brightness, speed and time fader use
● Compatible with other TITAN system console performance files
● Configurable group brightness, speed and time fader use
● Compatible with other TITAN system console performance files
